This product is designed for portable use but requires proper water inlet and outlet connections, adequate ventilation, level placement, and suitable drainage. All non-iCool pools require one (1) water inlet and one (1) water outlet sized at 19 mm (1"). Electrical supply must meet local requirements. Professional installation is recommended for commercial or high-use environments. Review all specifications prior to purchase.
The iCool Compact Series 5 Dual-Temp Portable Chiller & Heater is a powerful 2 HP all-in-one temperature control system engineered to cool or heat a single bath of up to 500 litres. Capable of maintaining water temperatures from 4ºC (39°F) up to 40ºC (104°F), this unit is ideal for cold therapy, hot therapy, and contrast recovery setups.
Designed and manufactured in Australia, the Compact Series 5 Dual-Temp delivers professional-grade performance in a portable, non-permanent format.
Built on a marine-grade aluminium chassis with a heat-cured Blaze Blue epoxy coating, the Compact Series 5 Dual-Temp is engineered for durability in demanding recovery environments.
A titanium heat exchanger paired with commercial-grade copper plumbing ensures excellent corrosion resistance and long-term reliability for both heating and cooling cycles.
- Cooling Power: 5000 W (down to 4ºC)
- Heating Power: 5000 W (up to 40ºC)
- Sound Level: 59 dBA @ 1.5 m
- Recommended Pool Volume: Up to 500 L
- iCool Pools: Connections included as standard
- Non-iCool Pools: Require 1× inlet and 1× outlet (19 mm / 1")
- Operation: Suitable for continuous 24/7 use
- Display: 10-inch Full HD capacitive splash-proof touch screen
- Software: iCool-developed control system
- Remote Control Screen: Optional
- Wi-Fi Control: Yes (with built-in screen model)
- Safety: 30 mA earth-leak device with instant shutdown
- Power Plug: Heavy-duty 3-pin (UK, US, AUS, or EU)
- Compact Series 5 Dual-Temp Chiller / Heater Unit
- 10-inch HD built-in splash-proof touch screen
- Industrial water circulation pump
- 220V: Davey QB035 spa-type pump
- 110V: Marlin ECO6000 world-voltage pump
- Complete hose set with iCool quick-release fittings:
- 1× 18 mm × 3000 mm
- 1× 18 mm × 500 mm
- 1× 12 mm × 3000 mm
- Standard pool fittings for 19 mm (1") outlets
- Power plug to suit country
Full setup and operation details are included in the installation manual. Additional guidance is available via the iCool support page and YouTube channel.
- Horsepower: 2 HP
- Cooling Power: 5000 W
- Heating Power: 5000 W
- Temperature Range: 4ºC – 40ºC (39°F – 104°F)
- Max Pool Volume: 500 L
- Net Dimensions: 650 × 550 × 350 mm
- Net Weight: 36 kg (79 lb)
- Sound Level: 59 dBA @ 1.5 m
- Country of Origin: Designed & manufactured in Australia
